3600RPM Small Portable Diesel Generator

  • 1
  • 2

Brand Name : ACEPOW

Model Number : AP1600-3S

Certification : CE,ISO, SASO

Place of Origin : Fujian, China

MOQ : 1 PCS

Price : Negotiate

Payment Terms : L/C, D/P, T/T

Supply Ability : 10000SETS/YEAR

Delivery Time : 25 DAYS

Packaging Details : NUDE PACKING,PLYWOOD CASE

Cooling system : Air cooling

type : air cooled diesel generator

Usage : Emergency Crew

After-sales service provided : Online support,Free spare parts

Condition : New

Driven type : Electric

Name : Hot Sale Air cooled Generator 6kva Silent Generator

Product name : silent air cooled wind kva diesel generator portable

Engine type : 178 f,Air-cooled Diesel Engine,1-Cylinder,4-stroke

Contact Now

Single Cylinder Air Cooled Diesel Generator 12kva 12kw Silent Mobile Portable Generators Genset Canopy

Features :
Chinese Engine
Chinese Alternator , Class H
Speed governor : Mech governor

Lockable battery isolator switch
Powder coated canopy
Vibration isolators between engine / Alternator and base frame
Integrated wiring design
High water temperature protection
Steel base frame with forkslots
100% test on idle load , fully load and 10% overload before shipment
ISO9001 quality control system and CE certification.
1 year guarantee

Adopt International quality standards, to meet high quality requirement
Good reputation for Reliable quality & Reasonable price

TECHNICAL DATA :

Model AP16000S(-3)
Frequency [Hz] 50 60
Voltage [V] 220,230,240,110/220,115/230,120/240,220/380,230/400,240/415
Rated Power [Kva] 11.0(13.75) 12.0(15.0)
Max. Power [Kva] 12.0(15.0) 13.0(16.0)
Phase Number Single/Three
Excitation Transistorized Self-excitation , brush
Power Factor Cos Φ 1.0(0.8)
Insulation Grade F
Fuel Capacity [L] 26
Noise Level [Db](@ 7m) 75
Engine Model AP292F
Engine Type 2-cylinder ,4-Stroke, Air-cooled
Starting System Electric Starting
Broke * Stroke [mm] 2-92*75
Displacement [L] 0.997
Compression Ratio 19
Rated Rotation Speed [rpm] 3000 3600
Rated Power [Kw] 14.0 15.0
Lube [L] 2.75
Fuel Type 0#(summer), -10#(winter) diesel oil
Lube SAE10W30 ( above CD grade )
Overall Diemension [mm] ( L*W*H) 1250*650*760
Net Weight [Kg] 340
